The Walkie Electric Stacker stands out as an essential piece of material handling equipment tailored specifically for small to medium-scale warehouses, factories, and supermarkets. This innovative machine not only simplifies the process of low-level stacking but also enhances operational efficiency through its intuitive design. Featuring a compact form that allows for remarkable maneuverability in tight spaces, the Walkie Electric Stacker can effortlessly navigate aisles packed with inventory. Users benefit from its straightforward operation; even team members with minimal training can quickly grasp how to lift and transport loads safely and effectively. The stacker’s electric power eliminates manual strain while maximizing productivity, making it a game changer for businesses looking to streamline their logistics without sacrificing safety or speed. Ideal for tasks such as restocking shelves or organizing goods on pallets, the Walkie Electric Stacker is proving indispensable in environments where agility and accessibility are paramount.
Walkie Electric Stacker
₹265,000.00
In stock
The walk behind electric stacker is a highly beneficial material handling equipment for small to medium scale warehouses, factories, and supermarkets. Its easy operation and maneuverability make it ideal for low-level stacking.
|
Model No. |
HM-1808 |
HM-1809 |
||
|---|---|---|---|---|
| Characteristics | Drive Unit | Electric | Electric | |
| Operator Type | Walkie | Walkie | ||
| Capacity | kg | 1500 | 1500 | |
| Load Center Distance | mm | 600 | 600 | |
| Wheel Base | mm | 1231 | 1231 | |
| Weight | Service Weight (With Battery) | kg | 375 | 445 |
| Service Weight (Without Battery) | kg | 345 | 315 | |
| Wheel | Tyre Type Driving Wheels/Loading Wheels | PU | PU | |
| Size of Loading Wheels | mm | ⌀78 | ⌀78 | |
| Size of Driving Wheels | mm | ⌀210 | ⌀210 | |
| Size of Balance Wheel | mm | ⌀180 | ⌀180 | |
| Wheel Quantity | pcs | 4 | 4 | |
| Specification | Lift Height | mm | 1600 | 3000 |
| Mast Lower Height | mm | 2015 | 2035 | |
| Mast Extend Height | mm | 2015 | 3500 | |
| Lowered Height | mm | 85 | 85 | |
| Overall Length | mm | 1720 | 1720 | |
| Length to Face of Forks | mm | 355 | 355 | |
| Overall Width | mm | 800 | 800 | |
| Fork Dimensions (W*L) | mm | 54*160*1150 | 54*160*1150 | |
| Width across Forks | mm | 540/680 | 540/680 | |
| Lowered Height of Forks | mm | 90 | 90 | |
| Clearance | mm | 30 | 30 | |
| Aisle Width of Pallets (1000*1200 mm) | mm | 2256 | 2256 | |
| Aisle Width of Pallets (800*1200 mm) | mm | 2184 | 2184 | |
| Minimum Turning Radius | mm | 1390 | 1390 | |
| Performance | Travelling Speed, Laden / Unladen | km/h | 3.5/4.0 | 3.5/4.0 |
| Lifting Speed, Laden/Unladen | mm/s | 95/134 | 95/134 | |
| Lowering Speed, Laden/Unladen | mm/s | 130/94 | 130/94 | |
| Max. Grade Ability, Laden/Unladen | % | 05/07 | 05/07 | |
| Service Brake Type | Electronic | Electronic | ||
| Electric Engine | Driving Motor | kw | 0.65 | 0.65 |
| Lifting Motor | kw | 1.5 | 1.5 | |
| Battery Voltage / Capacity | V/ah | 24/75 | 24/75 | |
| Battery Size | mm | (260*172*214) *2 | (260*172*214)*2 | |
| Control System | 1212P-2501 | 1212P-2501 | ||
